Marca:
GESTERItem número.:
CT-C28Pedido (MOQ):
1Detalhes do produto
|
Application: To test the water vapour transmision of various fabric (moisture permeable fabric included) and non-woven fabric such as bat wool, space cotton, sportswear fabric and protective clothing etc.Standards: GB/T12704, GB/T21655, ASTM E96 (Procedure A, B, C, D, E), JIS L1099 Method A , BS 7209, ISO 8096 |
[if gte mso 9]>
|
Model |
GT-C2 8-1 |
GT-C2 8-2 |
|
W ater vapour permeability cups |
1 layer, 8pcs |
2 layers, 8pcs/layer |
|
Test chamber temperature |
RT~50℃ |
|
|
Resolution |
0.1℃ |
|
|
Accuracy of temperature |
±0.5℃ |
|
|
Weighing function |
No |
|
|
Testing method |
Upright cup method |
|
|
Humidity of testing chamber |
40%RH~95%RH |
|
|
Resolution |
0.1%RH |
|
|
Accuracy of humidity |
±1%RH |
|
|
Testing time |
0.1 ～ 999.9h (can be changed into “min”) |
|
|
Speed of circulating air |
0.1 ～ 0.8m/s |
|
|
Breathable area |
2826mm² (∮60mm GB12704) or 4534mm² (∮76mm ASTM E96) or 5408mm² (∮83mm BS 7209) or 2826mm² (∮60mm JIS L1099) |
|
|
Dimension |
900×950×1600mm |
|
|
Weight |
Approx.300kg |
Approx.310kg |
|
Power supply |
AC 220V 50/60HZ |
|
